| SPECIFICATION | SINGLE PHASE | THREE PHASE |
|---|---|---|
| Range | 1 KVA to 20 KVA | 5 KVA to 200 KVA |
| Input Voltage | 160V AC tO 260V AC | 330V AC tO 460V AC 30+N |
| Input Frequency | 45Hz to 55Hz | 45Hz to 55Hz |
| Protection | Overload/Short cricuit, Battery Deep Discharge, Battery Over Charge, Output Under/Over Voltage | |
| Output Voltage | 200/210/220/230/Volts | 380/400/415/Volts 30+n |
| Voltage Regulation | 1% FCor Input Variation and Step Load Change from 10% to 100% ±2% 30+N | |
| Output Frequency | 50Hz with accuracy <±0.1% (Optional 60Hz) | |
| Wave Form | sinewave with THD <3% on linear load | |
| Power Factor | 0.8 Lagging to Unity | |
| Type Of Inverter | DPS Controlled Double Update Sine Modulated PWM | |
| Nominatio DC bus VOLTAGE | 180/192 VOLTS DC | 360/384 VOLTS DC |
| Inverter Efficiency | Better that 982% | |
| Overload | 125% for 10 minutes, 300% for 10ms | |
| Indications & Metering | LED PANEL DISPLAYING Input/Output Voltage, Input/ Output Frequency. Battery Voltage, Output Load, Operating Mode(Mains/Battery), Overload/Short Circuit, Battery Low Self Diagnostic Check, Output Status(On/Off), Audio Alarm, Battery Low and Overload | |
| Charge Type | IGBT Based Smart Charger | |
| Back UP Time | As per requirement |
